Built-in capable

• Front-breathing system allows the unit to be used built-in

Stainless steel doors

• Professional look in high quality stainless steel, with a unique curve to add a modern touch to any kitchen

Bottom freezer

• Convenient design keeps all refrigerated storage at eye level for easier use

Digital thermostats

• Separate digital controls located on the door let you adjust the refrigerator and freezer sections, with a digital display for added convenience

Adaptive intelligent technology

• Innovative sensors allow the unit to adjust to your habits, reading your patterns to manage the temperature based on the frequency of door openings and grocery loading

Adjustable glass shelves

• Spill-proof safety glass for durable and easy-to-clean storage that can be rearranged as needed

Adjustable door storage

• Three door racks can be adjusted in height to accommodate a variety of sizes

Fixed bottle door rack

• Lower door rack is ideal for storing tall condiments

Wine shelf

• Store bottles safely on an adjustable scalloped steel rack

Humidity controlled crisper

• Large crisper drawer allows you to ensure the optimum storage of fruits and vegetables

ZeroZone deli drawer

• Slide-out drawer allows you to store meats and other deli items at a slightly colder temperature for long-lasting freshness

Multibox storage container

• Removable container with a silicone lid and air-tight seal offers a convenient way to store smaller food items with a strong odor, such as blue-vein cheeses or onions

Interior LED refrigerator light

• Automatically illuminates when you open the door

Removable transparent freezer drawers

• Unique freezer design keeps the cold inside, even when the door is opened

Open door alarm

• Audible and visual alarm will alert if the doors have been left ajar for over 2 minutes

High temperature alarm

• Audible and visual alarms will alert if the temperature in the refrigerator or freezer compartment is too high

LED visual alarms

• All alarms are both audible and visual, with lamps in the control panel that will illuminate when the alarm is sounded

No-frost operation

• Frost-free freezer section and automatic defrost refrigerator offer low maintenance operation

Intensive cooling & freezing function

• Allows you to rapidly cool the refrigerator or freezer section, ideal for bringing newly loaded groceries to a safer storage temperature

Child lock

• Temperature controls include a locking function to prevent accidental setting changes

Factory reversible door swing

• Unit ships RHD unless ordered reversed in our factory. The doors are not user-reversible

100% CFC free

• Environmentally friendly design without ozone-damaging chemicals

Attributes
Defrost System	Frost-Free
Dispenser Type	None
Ice Maker	No
Number of doors	2
Style	Counter Depth
Type of Shelves	Glass

Colors
Default	Platinum

default
Brand	Summit
Category	Refrigeration
Color	Platinum
Group	Appliances
Sub Category	Bottom Mount

Overview
Amps	1.5
Cabinet	Platinum
Canadian Electrical Safety	ULC
Capacity	11.6 cu.ft. (328 L)
Compressor Warranty	5 Years
Defrost Type	Frost-Free/Automatic
Depth	25.25" (64 cm)
Depth with door at 90°	47.0" (119 cm)
Depth with Handle	27.25" (69 cm)
Door	Stainless Steel
Energy Usage/Year	380.0kWh/year
Height of Cabinet	73.88" (188 cm)
Height to Hinge Cap	74.38" (189 cm)
Parts & Labor Warranty	1 Year
Shipping Weight	200.0 lbs. (91 kg)
US Electrical Safety	UL
Voltage/Frequency	115 V AC/60 Hz
Weight	175.0 lbs. (79 kg)
Width	23.63" (60 cm)
Width with Door Open	24.63" (63 cm)

Refrigerator-Freezer
Adjustable Shelves	Yes
Compressor Step Depth	5.0" (13 cm)
Compressor Step Height	8.0" (20 cm)
Compressor Step Width	16.5" (42 cm)
Condensor Location	Rear of Unit
Crisper Cover	Glass
Crisper Finish	Transparent
Crisper Qty	2
Door Swing	RHD
Drawer Qty	5
Fan Type	Interior and Exterior
Freezer - Capacity	3.46 cu.ft
Freezer - Interior Depth	13.0" (33 cm)
Freezer - Interior Height	24.0" (61 cm)
Freezer - Interior Width	16.5" (42 cm)
Freezer - Temperature Range	-6º to 6ºF
High Side PSI	215.0
Interior Drawers	Yes
Interior Light	Yes
Level Legs	2
Low Side PSI	36.0
Refrigerant Amount	5.11 oz.
Refrigerant Type	R134a
Refrigerator - Capacity	8.15 cu.ft
Refrigerator - Full Door Shelves	3
Refrigerator - Interior Depth	17.5" (44 cm)
Refrigerator - Interior Height	38.5" (98 cm)
Refrigerator - Interior Width	19.25" (49 cm)
Refrigerator - Shelf Qty	3
Refrigerator - Shelf Type	Glass and Scalloped
Refrigerator - Temperature Range	34º to 46ºF
Reversible	Factory Reversible
Thermostat Type	Digital
Wine Bottle Shelving	Yes
