30-Inch 5-Burner Dual Fuel Convection Slide-In Range with Baking Drawer
- Model:KSDB900ESS
- Color:Stainless Steel
-
Description:
This versatile dual fuel range provides a Baking Drawer that adds more options to the oven. The separate compartment allows you to bake at a different temperature. This range also features flawless cooking results from Even-Heat™ True Convection. The unique bow-tie design and convection fan ensure the entire oven is heated to, and stays at, the perfect temperature.Baking Drawer : Adds more cooking options to the oven. The separate compartment allows you to keep warm, slow cook or bake at a different temperature and keep dishes warm.Glass Touch Controls : Offer an intuitive, easy-to-use touch screen experience.Side Trim Accessory Kit : This optional accessory kit will cover damaged countertops and unfinished edges from an old slide- in range to make them beautiful again. Trim pieces come in black, white and stainless to seamlessly match your new range.Continuous Interlocking Grates : Provide a level cooking surface that lets you easily change burners and move pots and pans across the entire range.SatinGlide® Max Racks : Move smoothly in and out, allowing effortless loading and unloading, even with large or heavy dishes.Even-Heat™ True Convection : Produces flawless results. The unique bow-tie design and convection fan ensure the inside of the entire oven is heated to, and stays at, the perfect temperature.Steam Rack : Offers the ability to provide additional moisture to the inside of the oven, enhancing cooking results.7.1 cu ft Total Capacity : This electric slide-in range provide an extra-large cooking capacity in the oven for multiple dishes at once and gives you the flexibility of a separate temperature zone in the baking drawer.5 burners (5k, 8k, 9.2k, 15k and 19k) : Provides the perfect range of cooking power from 5,000 to19,000 BTU, so you can go from a rolling boil to a delicate simmer.8K Center Oval Burner : Fits large griddles and other longer cookware on this 8,000 BTU fifth burner so they heat evenly on the range top.EasyConvect™ Conversion : Takes the guesswork out of convection cooking by converting conventional settings for recipes to convection settings for you.FIT Guarantee : Is our promise to flawlessly fit slide-in ranges designed for an existing cutout of 30" width, countertop depth of 24"-25", cabinet depth of 23"-24" and countertop height of 36".Aqualift® : Cleans your oven in less than an hour without odors and at a temperature below 200°F. This innovative system combines low heat with water to release baked-on spills.
Quick Specs:
:
Five
:
Griddle
:
One
:
Sealed Burner
:
Slide-In
:
30 inch
Baking Drawer
- Adds more cooking options to the oven. The separate compartment allows you to keep warm, slow cook or bake at a different temperature and keep dishes warm.
- Offer an intuitive, easy-to-use touch screen experience.
- This optional accessory kit will cover damaged countertops and unfinished edges from an old slide- in range to make them beautiful again. Trim pieces come in black, white and stainless to seamlessly match your new range.
- Provide a level cooking surface that lets you easily change burners and move pots and pans across the entire range.
- Move smoothly in and out, allowing effortless loading and unloading, even with large or heavy dishes.
- Produces flawless results. The unique bow-tie design and convection fan ensure the inside of the entire oven is heated to, and stays at, the perfect temperature.
- Offers the ability to provide additional moisture to the inside of the oven, enhancing cooking results.
- This electric slide-in range provide an extra-large cooking capacity in the oven for multiple dishes at once and gives you the flexibility of a separate temperature zone in the baking drawer.
- Provides the perfect range of cooking power from 5,000 to19,000 BTU, so you can go from a rolling boil to a delicate simmer.
- Fits large griddles and other longer cookware on this 8,000 BTU fifth burner so they heat evenly on the range top.
- Takes the guesswork out of convection cooking by converting conventional settings for recipes to convection settings for you.
- Is our promise to flawlessly fit slide-in ranges designed for an existing cutout of 30" width, countertop depth of 24"-25", cabinet depth of 23"-24" and countertop height of 36".
- Cleans your oven in less than an hour without odors and at a temperature below 200°F. This innovative system combines low heat with water to release baked-on spills.
| ADA Compliant | |
| ADA Compliant | ADA Height and Operation Compliant |
| Amps | |
| Amps | 40 |
| Attributes | |
| Number of Burners | Five |
| Number of Ovens | One |
| Special Burner | Griddle |
| Style | Slide-In |
| Type of Burners | Sealed Burner |
| Width | 30 inch |
| Auto Re-ignition | |
| Auto Re-ignition | No |
| Bake Element Power | |
| Bake Element Power | 3600W |
| Broiler Element Power | |
| Broiler Element Power | 4000W |
| Broiler Location | |
| Broiler Location | Top of Oven |
| Center Rear Element-Burner Power | |
| Center Rear Element-Burner Power | 8000 BTU |
| Center Rear Element-Burner Type | |
| Center Rear Element-Burner Type | Sealed Burner |
| Colors | |
| Default | Stainless Steel |
| Convection Element Power | |
| Convection Element Power | 3200 |
| Convection Element Type | |
| Convection Element Type | Fan |
| Convection Functions | |
| Convection Functions | Bake,Broil,Roast |
| Cooktop Element Style | |
| Cooktop Element Style | Gas Burner |
| Cooktop Surface Color | |
| Cooktop Surface Color | Color Coordinated |
| Cooktop Surface Material | |
| Cooktop Surface Material | Stainless Steel |
| default | |
| Brand | KitchenAid |
| Category | Range |
| Color | Stainless Steel |
| Group | Appliances |
| Sub Category | Dual Fuel |
| Dimensions | |
| Capacity (Cu Ft) | 7.10 inch |
| Carton Depth | 30 9/16 inch |
| Carton Height | 43 1/2 inch |
| Carton Width | 31 1/2 inch |
| Depth Closed Excluding Handles | 26 3/8 inch |
| Depth Closed Including Handles | 28 7/8 inch |
| Depth With Door Open 90 Degree | 48 3/4 inch |
| Gross Weight | 235 inch |
| Height | 36 inch |
| Net Weight | 215.0 inch |
| Width | 29 7/8 inch |
| Dimensions|Capacity(FT3,cubic feet) | |
| Dimensions|Capacity(FT3,cubic feet) | 7.10 |
| Display Color | |
| Display Color | Red/White |
| Display Type | |
| Display Type | Digital |
| Door Type | |
| Door Type | Metal & Glass |
| Drawer Type | |
| Drawer Type | Baking Drawer |
| Fuel Type | |
| Fuel Type | Dual Fuel |
| General | |
| Automatic Convection Conversion Temperature Adjust | Automatic Convection Conversion Temperature Adjust : Yes |
| Grate Details | |
| Grate Details | Cast Iron Grates,Continuous,Dishwasher Safe,Matte Finish |
| Griddle | |
| Griddle | Included |
| Handle Color | |
| Handle Color | Stainless Steel |
| Handle Material | |
| Handle Material | Metal |
| Handle Type | |
| Handle Type | Towel Bar |
| Heating Element On Indicator Light | |
| Heating Element On Indicator Light | No |
| Hidden Bake | |
| Hidden Bake | Yes |
| Hot Surface Indicator Light | |
| Hot Surface Indicator Light | No |
| Ignition Type | |
| Ignition Type | Electronic |
| Interior Color | |
| Interior Color | Grey |
| Interior Depth (in.) | |
| Interior Depth (in.) | 20 1/8 |
| Interior Height (in.) | |
| Interior Height (in.) | 22 1/8 |
| Interior Width (in.) | |
| Interior Width (in.) | 24 1/8 |
| Knob Color | |
| Knob Color | Stainless Steel |
| Knob Type | |
| Knob Type | Metal |
| Left Front Element-Burner Power | |
| Left Front Element-Burner Power | 19,000 BTU |
| Left Front Element-Burner Type | |
| Left Front Element-Burner Type | Sealed Burner |
| Left Rear Element-Burner Power | |
| Left Rear Element-Burner Power | 5000 BTU |
| Left Rear Element-Burner Type | |
| Left Rear Element-Burner Type | Sealed Burner |
| Light Type | |
| Light Type | Incandescent |
| LP Convertible | |
| LP Convertible | Yes |
| Number of Cooking Element-Burners | |
| Number of Cooking Element-Burners | 5 |
| Number of Grates | |
| Number of Grates | 2 |
| Number of Oven Lights | |
| Number of Oven Lights | 2 |
| Number of Oven Racks | |
| Number of Oven Racks | 3 |
| Number of Rack Guides | |
| Number of Rack Guides | 7 |
| Oven Control Type | |
| Oven Control Type | Electronic Touch |
| Oven Cooking System | |
| Oven Cooking System | Convection |
| Oven Rack Type | |
| Oven Rack Type | 1 Max Capacity, 1 Gliding Roll-Out, 1 Steam Rack |
| Oven Self-Cleaning | |
| Oven Self-Cleaning | AquaLift® Self Clean |
| Oven Window Size | |
| Oven Window Size | Large |
| Power Cord Included | |
| Power Cord Included | No |
| Power On Indicator Light | |
| Power On Indicator Light | Yes |
| Power Outage Compatible | |
| Power Outage Compatible | No |
| Prop 65 | |
| Prop 65 | Standard |
| Range Type | |
| Range Type | Slide-in |
| Right Front Element-Burner Power | |
| Right Front Element-Burner Power | 15,000 BTU |
| Right Front Element-Burner Type | |
| Right Front Element-Burner Type | Sealed Burner |
| Right Rear Element-Burner Power | |
| Right Rear Element-Burner Power | 9200 BTU |
| Right Rear Element-Burner Type | |
| Right Rear Element-Burner Type | Sealed Burner |
| Selections | |
| Selections | Baking Drawer Bake,Baking Drawer Keep Warm,Baking Drawer Slow Cook,Clock,Cook Time Indicator,Delay Start,Keep Warm Setting,Proofing,Steam Bake,Warm Zone |
| Size (in.) | |
| Size (in.) | 30 |
| UL | |
| UL | UL |
| Volts | |
| Volts | 240 |
