Accessories
Combustible situation (Sold seperately)	BGRV2-3048H
Minimum CFM	1,200
Non combustible situation (Sold seperately)	BGRV2-3048 / BGRV2-1248
Recommended hood (Sold seperately)	HCB48-12_N
Square handle option (Sold seperately)	AH-R48

Cleaning
Dishwasher proof trivets	true

Colors
Default	Stainless Steel

Controls
Main oven- Electronic Oven Control	true
Main oven- Internal light	true
Metal illuminated dials	true
Secondary Oven- Electronic Oven Control	true
Secondary Oven- Internal light	true

COOKTOP FEATURES
Gas Cooktop- Sealed range top	true
Vent trim included	Flat vent trim

Cooktop Performance
Max burner power	19000BTU
Power back centre	13000BTU
Power back centre (2)	13000BTU
Power back left	13000BTU
Power back right	13000BTU
Power front centre	15000BTU
Power front centre (2)	15000BTU
Power front left	19000BTU
Power front right	19000BTU
Sealed Dual Flow Burners™	8
Simmer on all burners	140°F
Total cooktop power	120000BTU

default
Brand	Fisher and Paykel
Category	Range
Color	Stainless Steel
Group	Appliances
Sub Category	Gas

Gas Requirements
Fitting and pipe	½ NPT, min. ⅝" ∅ flex line
Supply Pressure	LPG Pressure 11" to 14" W.C

OVEN FEATURES
Main oven- Broil pan	true
Main oven- Infrared Broiler	true
Secondary Oven- 3/4 extention racks	2

Oven functions
Main oven functions	3
Main oven- Bake	true
Main oven- Broil	true
Main oven- Convection Bake	true
Secondary oven functions	2
Secondary Oven- Bake	true
Secondary Oven- Proof	true

Oven Performance
Main oven- Bake	22000BTU
Main oven- Broil	22000BTU
Main oven- Shelf positions	5
Main oven- Total Capacity (AHAM)	5.3cu ft
Main oven- Usable Capacity (AHAM)	3.9cu ft
Secondary Oven- Bake	18500BTU
Secondary Oven- Capacity total (AHAM)	2.4cu ft
Secondary Oven- Capacity usable (AHAM)	1.7cu ft
Secondary Oven- Shelf positions	5
Total oven capacity	7.7cu ft

Power Requirements
Electric circuit	3 wire
Rated current	15
Supply Frequency	60
Supply voltage	120

Product Dimensions
Depth (excluding handle and dials)	29 1/8"
Height (excluding vent trim)	35 3/4 - 36 3/4"
Width	47 7/8"

Safety
Full extension telescopic racks	3

Style And Series
Product Style	Professional
